The toggle switch on the bottom takes the place of your finger on the round directional control switch. The user does not need to keep their finger on the round directional control switch. This controller can pan continuously with the help of the toggle switch on the bottom. The 4 normal arrows make some people think it will only go in four directions. Such as, both up and to the right at the same time. The eight arrows on this image is just a Photoshop addition of 4 more arrows to show visually that every controller can make the pan tilt head move diagonally. This image shows 8 arrows on the round directional control switch. The center image shows a custom hand held remote control. The left image shows a normal Hand held remote control. Close-up of the bottom part of the hand held remote control. Up and Right, Down and Right Up and Left, Down and Left. Speed is continuously adjustable using the slide speed control. The hand held remote control has a 4 foot long cable. The camera may have a telephoto lens and show only a small amount above and below the center lines. The camera may have a wide angle lens and show much more above and below the center lines. All vertical measurements are taken from the center of the image as seen through the camera. Auto mode: -sweeps an arc of 45, 90 or 340 degrees. Power Source -Uses 4 'AA' cells or 6 to 8 VDC external power supply. Dimensions: -4' Wide x 4.5' High x 5.75' Long Weight: -Weight of motor only is 30 Oz. Mounting: -Standard 1/4'- 20 thread top & bottom, inverted mounting is okay. Hand held remote control: - Has a 4 foot long cable. Maximum Cable length: - 600 feet by extending the control cable. Two motors: -allows for diagonal movements, you can pan and tilt at the same time Maximum Load: -6 pounds in upright position. (Continuously adjustable) Tilt speed: - 1 degrees per second to 3 degrees per second (Continuously adjustable). Pan speed: -3 degrees per second to 12 degrees per second. Tilt movement: -+15 degrees to -15 degrees in vertical plane (30 degrees total). # MP-50ft 50 foot extension cable # MP-PS 120VACb Battery eliminator Manufactures Specifications: Pan movement: -+170 degrees to -170 degrees in horizontal plane (340 degrees total).
We supply all the equipment necessary for a complete system. The bottom has a Standard 1/4'- 20 thread for your tripod or bracket.
The top has a Standard 1/4'- 20 thread for your camera. Uses 4 'AA' cells or 6 to 8 VDC external power supply.
The hand held remote control has a cable 4 foot long.Īuto mode sweeps an arc of 45, 90 or 340 degrees. They operate for years, have a thick plastic case, brass worm gears, no backlash, a light touch remote control. 170 degree Pan to the right and 170 degree Pan to the left. 15 degree Vertical Tilt up and 15 degree Vertical Tilt down.ģ0 degree total Vertical Tilt. Speed is continuously adjustable from 3 to 12 degrees per second.
